Luxpower 12kW Hybrid Single Phase LXP

• The Luxpower 12kW Hybrid Inverter, model LXP12K, is prepared to advance your solar power system. An inverter for solar panels and solar power is the Luxpower Hybrid Inverter.
• The DC electricity produced by your solar panels is converted into AC electricity by this solar inverter with battery and solar panels. It can connect to solar panels and use the lithium ion battery to store energy.
• For installers, the Luxpower 12kW Hybrid inverter is a fantastic inverter. Because it is a hybrid inverter, it can be used with grid-tied solar as well as off-grid inverters.
• This pure sine wave solar inverter with lithium battery is a fantastic solution for solar systems and for solar power installers. It was made with solar systems in mind specifically.
• A solar inverter made by LuxPowerTek is the Luxpower 12kW Hybrid inverter. The 5-year warranty is included with the Luxpower 12kW Hybrid Inverter.
• Additionally, it incorporates a color touchscreen LCD (liquid crystal display). Powerful and cutting-edge, the Luxpower 12kW Hybrid inverter is a solar inverter that can be applied in both home and commercial settings.
• Almost any lithium ion battery can be utilized with the LXP12K Luxpower type inverter for solar systems, and it has a seamless switching time. Since the battery’s nominal voltage is 48V, it can be used with a wide variety of solar batteries.

Solar Hybrid Inverter System Connection

A newly designed solar and energy storage hybrid solar inverter, capable to install in on-grid solar, off-grid solar and back-up systems. LXP Hybrid enables a programmable and scheduled smart solar energy storage system to help increase your solar energy self-consumption rate. The hybrid inverter can protect your home appliances from grid shortage, and balance your energy usage strategy to save energy bill.

Solar Hybrid Inverter Parallel Connection

Paralleling LXP inverters in one phase to extend the single phase system capacity for either hybrid or AC coupled energy storage applications. Paralleling LXP inverters (single phase inverters) to build a three phase system for either hybrid or AC coupled energy storage applications. Smart paralleling algorithm enable multiple configurable working modes under on-grid, off-grid or micro grid applications.

Overview of the Connection Ports

Specifications

DC PV Input

Luxpower 12kW Hybrid Single Phase LXP

• Max DC Input for Single MPPT: 12 000W / 7 000W / 7 000W
• Maximum PV Input: 18 000W
• DC Input Voltage Range: 100VDC-600VDC
• Nominal DC Input Voltage: 360VDC
• Full Power MPPT Voltage Range: 230VDC-500VDC
• Maximum DC Input Current: 25A / 15A / 15A
• MPPT Number / Strings per MPPT: 3(2/1/1)

AC Output (Grid)

Luxpower 12kW Hybrid Single Phase LXP

• Nominal Power: 12 000W
• Nominal AC Voltage: 240VAC
• Operating Voltage Range: 180VAC-270VAC
• Maximum Continuous AC Current: 50A @ 240VAC
• Nominal AC Frequency: 50Hz / 60Hz

Battery Parameters

Luxpower 12kW Hybrid Single Phase LXP

• Compatible Battery Type: Lead-acid / Lithium
• Nominal Battery Voltage: 48VDC
• Battery Voltage Range: 40VDC-60VDC
• Maximum Charge / Discharge Current: 250A
• Maximum Charge / Discharge Power: 12 000W

UPS Output (With Battery)

Luxpower 12kW Hybrid Single Phase LXP

• UPS Max Output Power: 12 000W
• UPS Nominal Output Voltage: 240VAC
• UPS Nominal Output Frequency: 50Hz / 60Hz
• UPS Nominal Output Current: 50A @ 240VAC
• Peak Power: 14Kw 10Min / 16Kw 5 Min / 20Kw 500ms
• Switching Time: <20ms

Build in BMS(Battery management System)

Luxpower 12kW Hybrid Single Phase LXP (See Full List)

• Pylon
• Dyness
• BYD
• Shoto
• Revov
• UZ Energy

LXP hybrid inverters support variable working modes

Generator Support

Luxpower 12kW Hybrid Single Phase LXP

This hybrid inverter can work with generator. There are Gen ports on the inverter for generator connection.

When generator is started, all the critical loads and non-critical loads will be supplied by the generator. Meanwhile battery will also be charged .

Environment Limit

Luxpower 12kW Hybrid Single Phase LXP

• Ingress Protection: IP65
• Operating Temperature Range: -25°C to +60°C
• Cooling: Fan
• Communication: RS485 / WIFI / CAN

Support & Monitoring

Luxpower 12kW Hybrid Single Phase LXP

• Free monitor system for remote monitoring, setting and update
• Wifi/4G/WLAN dongle available for different application for data collection
• IOS and Andriod APP are available
• Multi-level for system management
• Different account type for distributor, sub-distributor,installer and endusers
• Distributor and installer can create assist account for after sales
• Support batch settings for many inverters set together

Luxpower 12kW Hybrid Single Phase LXP

WIFI MODULE SPECIFICATION

MODEL	WI-FI
Size	86*55*23mm
Weight	34g
Protection Grade	IP65
Installation	Fixed on the device by screws
Rated voltage	5V
Maximum current	0.25A
External interface	HDMI
Indicator light	3
Operating temperature	-25℃~60℃
Storage temperature	-25℃~60℃
Local communication interface	RS485/TTL
Public network access	Wi-Fi
Baud rate	19200bps (Default)
Working frequency	2.412GHz – 2.484GHz
Maximum transmission rate	72Mbps
Communication distance	100m
Antenna gain	2.5dBi
Antenna	External antenna (External of the antenna are optional)
Traffic card	—
Watchdog	Software watchdog+hardware watchdog
Equipment layer communication protocol	Modbus-RTU
Network layer communication protocol	Modbus-TCP
Way of parameter settings	App/Remote server
Firmware update way	Local tools

A new design of solar and battery inverters that can use in on-grid solar, off-grid solar and back-up systems. The LXP Hybrid implements a programmable and scheduled intelligent solar storage system. This power inverter battery can help increase your solar energy self-use and protect your home appliances from grid shortages. Power battery inverter can also balance your energy use strategy to save on energy costs

MORE ABOUT LUXPOWER

”LuxpowerTek was founded in 2017 by a group of solar inverter engineers. They are dedicated to offering the most advanced solar inverter technology in the carbon neutral era, to integrators, installers, users. Over time, Luxpower has become one of the top solar inverter suppliers in the industry. Today, there are over 50000+ Luxpower systems installed all over the world, and the list is growing. Our platform offers the most accessible monitoring to all roles from the chain, products ranging from residential to commercial, service is always our first priority.

We are committed to making our users benefit from the sun and enjoy life.”

”Luxpower has a professional solar inverter engineers team with more than 20 years of solar inverter design experience. We are committed to providing smart energy for areas with or without electricity.”

”Luxpower has solar inverter distributors in Europe, North America, Latin, Asia pacific, Africa, Middle East. More than 50,000 solar power inverter systems have been installed all over the world. Feel free to contact us no matter what solar inverter you need.”
